AP-100C MPPT Solar Charge Controller
Tsim los ntawm Foshan Top One Power Technology Co., Ltd.

Lub AP-100C yog 100-amp MPPT hnub ci them nqi hluav taws xob tsim los ntawm Foshan Top One Power Technology Co., Ltd., ib lub tuam txhab nyob hauv Foshan, Guangdong, uas tau tshwj xeeb hauv kev tsim cov khoom siv hluav taws xob tauj dua tshiab txij li xyoo 2003. Ua rau lub hnub ci loj dua, nws yog qhov zoo tshaj plaws rau kev lag luam hauv chaw nres tsheb hnub ci, kev lag luam hauv chaw nres tsheb thiab kev sib txuas lus kev ua haujlwm, qhov twg txhua watt tsim los ntawm koj cov panels yog qhov tseem ceeb.

Ib qho tseem ceeb ntawm AP -100C yog nws cov roj teeb tsis siv neeg paub txog qhov hluav taws xob. Nws ua haujlwm nrog 12V, 24V, 36V thiab 48V roj teeb tshuab yam tsis muaj kev teeb tsa ntawm phau ntawv. Qhov no txhais tau hais tias nws tuaj yeem siv rau hauv kev teeb tsa sib txawv yam tsis tas yuav muaj kev hloov kho lossis kev pheej hmoo ntawm kev ua yuam kev. AP-100C txhawb nqa cov roj ntsha uas txhaws, AGM, gel, thiab LiFePO₄ roj teeb, thiab nws cov txheej txheem them peb theem ua haujlwm zoo.

MPPT nrhiav kev ua tau zoo yog nyob ntawm 99% lossis zoo dua. Qhov no tsis yog kev lag luam hype xwb; nws txhais tau hais tias AP-100C tuaj yeem hloov kho txuas ntxiv mus nrhiav qhov chaw ua haujlwm zoo tshaj plaws rau koj lub hnub ci vaj huam sib luag, tshem tawm lub zog siab tshaj plaws tsis hais hnub ci. Rau 48 V system, nws tuaj yeem ua haujlwm txog li 5,600 W ntawm PV input; rau siab dua-voltage 96 V systems, daim duab no nce mus rau 11,200 W.

AP-100C siv qhov kev txawj ntse peb -theem them cov txheej txheem suav nrog kev them nqi tam sim no (MPPT), sib npaug thiab them nqi ntab. Kuj tseem muaj hom roj teeb uas tsis muaj roj teeb uas tso cai rau lub hnub ci kom pub cov khoom thauj ncaj qha thaum cov roj teeb tsis txuas nrog. Yog tias koj xav txuas nws rau kev saib xyuas tej thaj chaw deb, muaj RS485 qhov chaw sib txuas lus.

Kev tiv thaiv yog muab tiv thaiv rov qab polarity, tshaj -voltage, nyob rau hauv -voltage thiab tshaj- kub. Qhov kub thiab txias - kiv cua tswj kom nws txias yam tsis muaj suab nrov txhua lub sijhawm.
